Panasonic AG-UX90 4K/HD Professional Camcorder

Panasonic AG-UX90 4K/HD Professional Camcorder

₹ 1,30,000
₹ 1,69,999
Brands: Panasonic
SKU: AG-UX90ED8
Delivery date: 3-5 days
Availability: Out of stock
/safe-checkout-seal
Panasonic AG-UX90 4K/HD Professional Camcorder
.

BRAND NEW ITEM

.

GST INVOICE AVAILABLE

.

BRAND WARRANTY

.

CUSTOMER SUPPORT

.

Easy Returns & Exchanges

.

Authentic Products

.

100% Secure Payment

The Panasonic AG-UX90 4K/HD Professional Camcorder records UHD 4K at up to 30p, and FHD up to 60p in variable frame mode. The camera supports 59.94, which is analogous to NTSC, making the camera compatible with US broadcast standards. It features an integrated 15x optical zoom lens and a 1"-type sensor, and can record UHD 4K and Full HD in MOV and MP4. The camera is also capable of recording HD in the AVCHD format.

The AG-UX90 offers gamma settings for eight different scenarios, and manual control rings for iris, zoom, and focus. To monitor the status of all settings and perform critical focusing functions, the camcorder features both a high-quality 3.5" LCD touch screen, and a full-color LCoS 0.24" viewfinder with 1,560,000 dots of resolution. It incorporates two SD slots that allow for simultaneous recording in UHD and HD. You can also choose relay recording, which allows the recording to shift from one card slot to the other as the card fills up.

Panasonic Optical Technology

The integrated Leica Dicomar 15x zoom lens was designed specifically for professional HD video production, and features a 24.5mm equivalent focal length on the wide end of the zoom, when recording FHD for a 24.5-367.5mm (35mm equivalent) zoom range and a 35.4 to 531mm (35mm equivalent) zoom range when shooting in UHD. The lens combines four lens groups and incorporates Optical Image Stabilization (OIS). When shooting in HD, it supports 5-axis hybrid image stabilization.

Digital Zoom

The AG-UX90 is equipped with 2x, 5x, and 10x digital zoom. Using the 20x optical zoom and digital zoom together yields a 25x zoom factor.

Manual Control Rings

Three manual rings, mechanical (cam-driven) zoom, focus, and iris allow you to operate as if you've got an interchangeable-lens camcorder, able to adjust either focus, zoom, or iris directly without having to select a control surface.

Intelligent Auto Focus

Features high-speed focusing, high-precision focus tracking, and high-focusing stability.

Customizable Auto Focus

You can adjust the AF speed, sensitivity and area width to fine tune the AF functionality to your tastes or the needs of the shot. The speed can be set from 1 to 7, the higher the number the faster the AF. The sensitivity likewise can be adjusted in steps from 1 to 10, with the higher value corresponding to being able to track faster-moving subjects. The adjustable area width can be adjusted to fine tune the auto focus selection.

Manual Focus

To assist you in setting and confirming focus, the following features are included:
  • Focus assist (expand and peaking): You can select from enlarging a part of the image to check the focus, or engaging focus peaking, which highlights the sharpest part of the image in a solid color. You can select to engage either or both functions simultaneously.
  • One-push AF: Temporarily activates AF when you are in manual focus mode, when you press the Push AF button.
  • Manual focus assist: For quick and accurate focus, this mode fine-tunes the focus adjustments you make using the focus ring.
  • Area functions: Enables you to touch the LCD screen and have the camera adjust focus to make that area sharp (can also be used for Auto Iris and screen brightness)

ND Filter

The AG-UX90 features a four-position (OFF, 1/4 ND, 1/16 ND, 1/64 ND) optical neutral density filter wheel.

Skin Detail Adjustment

Skin Detail smooths out fine detail on the face of your subject.

Eight-Mode Gamma

Drawing upon the technology of the high-end VariCam line, the UX90 features eight selectable gamma modes, including two cine-like gammas:
  • HD norm: For standard HD recording
  • SD norm: For standard SD recording
  • Filmlike 1: Reproduces more gradation in highlight areas than when shooting in HD
  • Filmlike 2: Reproduces more gradation in highlight areas than when shooting in Filmlike 1
  • Filmlike 3: Reproduces more gradation in highlight areas than when shooting in Filmlike 2
  • Cine-like D: The Cine-like mode shifted to prioritize dynamic range
  • Cine-like V: The Cine-like mode shifted to prioritize contrast
  • Still-like: Setting to match images captured with still cameras

Three-Position Gain Selection

There is a three-position gain selector, with L, M, and H settings. To each setting you can assign a gain value of 0, +3, +6, +9, +12, and +18 dB. There is also a Super Gain of +24 dB and +30 dB, only accessible via a user button.

Other Camera Image Settings

Three values (A/B/Preset) of white balance are selectable with an auto-tracking white function. The preset can be set to 3200K, 5600K, and Variable, which ranges between P2.4K and P9.9K. As with gamma, matrix setting includes a cine-like mode. H/V detail levels are adjustable, as are detail coring and skin tone detail. Chroma level, chroma phase, color temperature, and master pedestal are all adjustable as well. The camera offers four settings for knee point: Auto, Low, Mid, and High.

High-Quality, Multi-Format Professional AVCHD PH Mode

The AG-UX90 uses the AVCHD recording format, and also supports the high-image-quality PH mode. AVCHD complies with MPEG-4 AVC/H.264 high-profile motion picture compression technology. Boasting a compression efficiency that is more than twice that of the MPEG-2 system (such as HDV), this advanced video file format delivers superb image quality and low data rates. The PH mode was developed for AVCCAM by Panasonic exclusively for high-quality professional video production. This mode boasts a maximum AVCHD bit rate of 24 Mb/s (average: 21 Mb/s), and records 1920 x 1080 Full HD images. The AVCHD PH mode is also compatible with multiple HD formats, such as 1080i59.94, 1080p29.97, 1080p23.98, and 720p59.94.

Linear PCM Recording for High-Quality Sound

The AG-UX90 supports uncompressed 16-bit linear PCM 2-channel digital audio recording with PH mode for high-quality sound. Other modes employ Dolby Digital 2-channel audio recording.

Double-Slot SD Card System

Not only can you record continuously on two SD/SDHC/SDXC cards (up to 128 GB), relay recording lets you seamlessly record images onto two memory cards consecutively for added data security, and simultaneous recording records the same images onto two different memory cards to increase reliability when recording. The slot to be used can be switched during normal recording, and clips can also be copied between the two slots.
Note:
The AVCHD's maximum consecutive recording length is 12 hours. This cannot be extended even by using the relay function. Simultaneous recording cannot be combined with relay recording, VFR recording, or interval recording. Also, Rec Check and Last Clip Delete will not operate during simultaneous recording.

Other Recording Modes

Pre-Rec continuously stores in standby mode up to four seconds of MOV/MP4 video, and three seconds of AVCHD video, and this pre-record cache is only recorded to the P2 card once you press Record. This helps you get the shot every time, even if you miss the crucial moment by a couple of seconds. Interval Rec gives you automatic intermittent recording based on a set interval and recording time (1 sec, 10 sec, 30 sec, 1 min, 2 min) only in 1080p24. Rec Check checks the beginning and end of the last recorded clip. If you don't like it, Last Clip Delete enables one-button delete of that last clip. Scenes can be marked with up to 100 Index flags per clip (AVCHD mode only). Time Stamp appends the date and time onto recorded images, which is a crucial feature for evidential images.

Scene File / User File

The camera features a scene dial that allows you to choose an appropriate matrix of settings instantaneously. You can modify the six preset files if you'd like, one set of which can be stored internally in the camcorder. Up to eight sets can be stored on an SD memory card.

User Buttons

A total of 13 user buttons can be set to trigger any selection of 44 different camera functions.

High-Quality Color Viewfinder and LCD

The AG-UX90's color EVF uses a 0.45", approximately 1,560,000 dot-equivalent LCD display. It delivers bright, detailed, high-resolution images and a high response speed. The AG-UX90's LCD monitor has a 3.5", approximately 1,150,000-dot high-resolution panel. Various markers and grids can be displayed on the monitor/viewfinder, and with Mode Check, a list of the camera's settings can also be displayed on both.

XLR Input for Pro-Quality Audio

In addition to the internal high-performance stereo microphone, the AG-UX90 comes equipped with two-channel XLR audio input terminals with a 48V phantom power supply. The internal microphone, external microphone, or line input can be selected for each channel. Large, easy-to-use level dials are also provided.



Products specifications
ConfigurationCamcorder Only
Sensor TypeMOS
Special FeaturesXLR Mic Input
Sensor Size1"
ResolutionHigh Definition
Kit StyleBase
ModelAG-UX90
Write your own review Close Review Form
  • Product can be reviewed only after purchasing it
  • Only registered users can write reviews
*
*
Bad
Excellent
Amazing Camera
Amazing Camera with the Best Price
Sumit | 21/11/2020 3:11 pm
Was this review helpful? Yes No (0/0)
  • Panasonic AG-UX90 4K/HD Professional Camcorder
  • Panasonic 7.28V 43Wh Lithium-Ion Battery for DVX200 and CX10 (5900mAh)
  • Panasonic Battery Charger for AG-VBR & Other Batteries
  • AC Adapter
  • Microphone Holder Kit
  • Eyecup
  • Lens Hood
  • Input Terminal Cap
  • AC Cable



4K Optical Image Stabilization

The AG-UX90’s 15x optical zoom and wide angle lens (24.5 mm) ensures you get the shot you need, near or far. The i.Zoom function (HD mode only) increases the zooming capability to a maximum of about 25x zoom, while still maintaining high resolution. If needed, Digital Zoom (2x, 5x or 10x) gives you super-telephoto magnification without a significant drop in light intensity.

Easier Focusing in 4K

The AG-UX90 is equipped with intelligent auto focus technology, offering industry-leading focusing speed, tracking performance and image stability. This top-level performance is achieved through the primary focus algorithm, which assures accurate and quick focus adjustment. A high-precision, high-speed Micro Drive Focus Unit accurately tracks subjects, even when experiencing abrupt changes in focal distance.

The UX90 provides numerous options to optimize your settings, including adjustment of AF speed and sensitivity, as well as the width of the effective AF area. Other helpful features include one-push AF and on-screen focus assist with colored focus areas.. The UX90 also can be put in manual focus mode for manual adjustments with the focus ring.

Variety of Recording Formats

The camcorder’s variety of recording modes with selectable image quality, frame rate and bit rate settings are ideal for a wide range of applications, from cinema production to online distribution. Images can be recorded with a resolution of UHD (3840 x 2160)/30p or FHD (1920 x 1080)/60p. Versatile and easy-to-use MOV (QuickTime), MP4 and AVCHD file formats are supported.

VFR (2 fps to 60 fps)

Full HD Variable Frame Rate (VFR) recording can be set in 10 steps from 2 fps to 60 fps (60Hz) / 9 steps from 2 fps to 50 fps (50Hz).

Dual SD Memory Card Slots

The UX90 comes equipped with two SD cards slots, enabling options such as unlimited relay recording and simultaneous recording.

ROP iPad App: Wireless Camera Operation

The AG ROP app for iPad is available free of charge from the Apple App Store. It enables wireless remote control of the AG-UX90, with installation of a wireless module (optional AJ-WM50/AJ-WM30). In addition to a multitude of control functions, such as camera settings, picture quality adjustment, REC start/stop and menu setting, the AG ROP app allows control of the UX90's internal lens for remote operation of the i.Zoom, zoom and focus. It also displays a thumbnail view and a preview view, so sub-recording clips can be displayed as thumbnails and previewed on an iPad.





Image Sensor1-Chip 1" MOS Sensor
Effective Sensor Resolution8.59 MP
Gain0 to 30 dB (Native)
-3 to 30 dB (Expanded)
Minimum Illumination1.3 Lux at 1/30 Shutter Speed
White Balance Range2000 to 15,000K
Lens
Focal Length8.8 to 132mm
35mm Equivalent Focal Length35.4 to 531mm
Optical Zoom Ratio15x
Minimum Focusing Distance3.3' / 1.0 m
Filter Size67 mm
Camera
Shutter Speed1/2 to 1/8000 sec
Built-In ND FilterMechanical Filter Wheel with 2 Stop (1/4), 3 Stop (1/8), 4 Stop (1/16) ND Filters
Recording Media1 x SDXC UHS-I Card Slot
2 x SDXC Card Slots
Recording
Recording ModesMP4 4:2:0 8-Bit:
3840 x 2160p at 23.98/29.97 fps (100 Mb/s)
1920 x 1080p at 23.98/29.97/59.94 fps (50 Mb/s)
Variable Frame Rates1080p: 2 to 60 fps
1080p: 2 to 50 fps
Audio Recording2-Channel 16-Bit 48 kHz
Interface
Video Connectors1 x 1/8" (3.5 mm) TRRS A/V Output
1 x 1/8" (3.5 mm) TRRS A/V (Composite) Output
1 x HDMI (HDMI 2.0) Output
Audio Connectors2 x 3-Pin XLR Mic/Line Level (+48 V Phantom Power) Input
1 x 1/8" / 3.5 mm Stereo Headphone Output
Other I/O1 x USB Type-A
1 x USB Micro-B
Display
Display TypeLCD
Screen Size3.5"
Screen Resolution1,150,000 Dots
EVF
Screen Size.25"
EVF Resolution1,560,000 Dots
Power
Power Connectors1 x Barrel (11.4 to 12.6 VDC) Output
Power Consumption12.2 W
Environmental
Operating Temperature32 to 104°F / 0 to 40°C
Operating Humidity10 to 80%
General
Dimensions6.7 x 7.7 x 13.4" / 16.9 x 19.5 x 34 cm
Weight4.2 lb / 1.9 kg
Packaging Info
Package Weight9.8 lb
Box Dimensions (LxWxH)18.4 x 13.1 x 11.1"
