Atomos Shogun 7 HDR Pro/Cinema Monitor-Recorder-Switcher with Accessory Kit

Atomos Shogun 7 HDR Pro/Cinema Monitor-Recorder-Switcher with Accessory Kit

₹ 1,60,990
₹ 1,76,060
Brands: Atmos
SKU: ATOMSHG701 Shogun 7 Kit
Delivery date: 3-5 days
Availability: Out of stock
/safe-checkout-seal
Atomos Shogun 7 Kit
.

BRAND NEW ITEM

.

GST INVOICE AVAILABLE

.

BRAND WARRANTY

.

CUSTOMER SUPPORT

.

Easy Returns & Exchanges

.

Authentic Products

.

100% Secure Payment

Monitor and record up to 4K video and keep your monitor powered up and connected with this Atomos Shogun 7 HDR Pro/Cinema Monitor-Recorder-Switcher with Accessory Kit put together by B&H. This kit includes an Atomos 7" Shogun 7 HDR Pro/Cinema monitor-recorder-switcher and the Atomos Accessory Kit that includes two 5200mAh batteries, a fast charger, a USB 3.0 docking station, a D-Tap power cable, a 2.5mm camera control cable, four Master Caddy II drive caddies, a sun hood, an AC power adapter, and an HPRC hard flight case.

The versatile monitor features 4K HDMI and 12G-SDI input, 3000 cd/m² brightness, displays native HDR footage, supports custom LUTs, and it records footage up to 4K using the included Master Caddy II drive caddies. It also features live switching between camera streams and program output via its 12G-SDI inputs and outputs. Read more below about the items in this kit.

Atomos Shogun 7 HDR Pro/Cinema Monitor-Recorder-Switcher

Monitor, record, and switch in the field with the 7", 1920 x 1200 Shogun 7 HDR Pro from Atomos. This versatile on-camera recording monitor offers up to DCI 4K raw recording, HDMI and 12/6/3G-SDI inputs/outputs. With the AtomOS 10.4 firmware update, the Shogun 7 provides ISO recording of up to four HD-SDI camera streams plus program capture. Output your content for director or client viewing in Dolby Vision HDR using the Shogun 7, AtomOS10 platform, and a compatible display.

This touchscreen monitor supports resolutions up to DCI 4K (4096 x 2160) at 60p and up to 2K at 240p for slow-motion effects. Record to 2.5" SSDs using Apple ProRes Raw, ProRes, CinemaDMG (up to 30p), and Avid DNxHD codecs. Record all your event's action with live multicamera monitoring, recording, and switching between program and up to four 1080p60 SDI ISO camera streams. When used with Final Cut Pro, a fully configurable, multicam .xml can be generated for easier editing.

The Shogun 7's 10-bit (8+2 FRC) panel features 360-zone backlight, 3000 cd/m² brightness, and a 1,000,000:1 contrast ratio. Its native AtomHDR (log) display enables you to more accurately monitor your log gamma footage without having to view flat, washed-out images or use a LUT to compress the dynamic range and color space. Built-in presets accurately translate popular log formats from ARRI, Canon, Fujifilm, JVC, Nikon, Panasonic, RED, and Sony cameras.

Save editing time by tagging your footage on-the-fly and recording directly to Final Cut Pro x, Adobe Premiere, or Avid Media Composer formats (third-party plug-ins may be required for tagging).

Power the Shogun Inferno with a single Sony L-series battery; dual battery plates support hot swapping, enabling longer uninterrupted runtimes. For audio recording, the monitor supports balanced XLR inputs with +48V phantom power via a separately available audio breakout cable. Additional Shogun 7 features include genlock input, BNC timecode input, SDI/HDMI cross conversion, and a variety of on-screen exposure analysis, framing, focus assist, and other display tools.

Monitor

  • 1920 x 1280 resolution
  • 7" LCD screen with 360-zone backlight
  • 10-bit (8+2 FRC) monitoring processing
  • 3000 cd/m² brightness
  • 1,000,000:1 contrast ratio (with zone backlight on)
  • Output using Dolby Vision HDR
  • AtomHDR technology displays native HDR (log) display footage
  • Log gamma viewing presets for ARRI, Canon, Fujifilm, JVC, Nikon, Panasonic, RED, and Sony cameras
  • Custom 3D LUT support (.cube format)
  • Anamorphic de-squeeze: 2x, 1.5x, 1.33x
  • UHD 4K downscale for HD monitoring

Input/Output

  • 4K HDMI and 12G-SDI inputs/outputs
  • Four 3G-SDI or dual 12G-SDI inputs
  • SDI/HDMI cross conversion
  • Genlock input
  • Separately available audio breakout cable for XLR audio input

Recording & Switching

  • Up to DCI 4K60 recording in ProRes Raw, ProRes, CinemaDMG (4K30), or DNxHD
  • Live switch up to four ISO HD camera feeds with AtomOS 10.4 update
  • Generates a multicam .xml for easier editing in Final Cut Pro
  • 5-channel capture with four ISO feeds plus program
  • Slow-motion recording up to 1080p at 240 fps
  • Record to 2.5" SSD/HDD media using the included Master Caddy II
  • Pre-roll record (8 seconds in HD, 2 seconds in 4K)
  • Ten metadata fields

Additional Features

  • Dual Sony L-series battery slots support hot swapping for continuous power
  • Record 4K30p up to 2.2 hours with 2 x 7.4V, 7800mAh batteries
  • Record 4K30p up to 1.5 hours with 2 x 7.4V, 5200mAh batteries
  • Top and bottom 1/4"-20 mounting threads
  • 3.5mm headphone output port



Products specifications
Monitor TypeTFT LCD
Mount TypeWithout Mount
Size7"
Monitor Resolution1920 x 1080
BrandAtomos
Write your own review Close Review Form
  • Product can be reviewed only after purchasing it
  • Only registered users can write reviews
*
*
Bad
Excellent
  • Atomos Shogun 7 HDR Pro/Cinema Monitor-Recorder-Switcher
  • Master Caddy II with Screws
  • AC Power Supply (12V, 3A)
  • 4 x Wall Plug
  • EPP Carrying Case
  • Atomos Accessory Kit for Shogun/Ninja Inferno & Flame
  • HPRC Hard Flight Case
  • 2.5mm Female to Dual 2.5mm Male Control Cable
  • 2 x NP-F750 5200mAh Batteries
  • Fast Charger
  • USB 3.0 Docking Station
  • Coiled D-Tap to DC Barrel Cable
  • 4 x Master Caddy II Drive Caddies
  • AC Power Adapter
  • HDR Sunhood

no data

Display
Panel TypeIPS-Type LCD
Display Size7.2" / 18.3 cm
Screen Resolution1920 x 1200
Aspect Ratio16:9
TouchscreenYes
Maximum Brightness3000 cd/m2
Dynamic Contrast Ratio1,000,000:1
Bit Depth / Color Support8-Bit+FRC (1.07 Billion Colors)
Pixels Per Inch (ppi)325 ppi
Color Gamut105% DCI-P3
Real-Time LUT MonitoringSDR, HDR
Image ControlsAnamorphic De-Squeeze, Blue Only, False Color, Focus Peaking, Image Flip, Pixel-to-Pixel Zoom, Screen Markers, Vectorscope, Waveform, Zebra
I/O
Video1 x HDMI Type A (HDMI 2.0) Input
1 x HDMI Type A (HDMI 2.0) Output
1 x BNC (12G-SDI) Input
1 x BNC (12G-SDI) Input/Output
1 x BNC (12G-SDI) Output
2 x BNC (3G-SDI) Input
Embedded AudioHDMI: 8-Channel
HDMI: 2-Channel
SDI: 12-Channel
Audio1 x 10-Pin LEMO Input
1 x 3.5 mm Headphone Output
Built-In SpeakerNone
Power1 x Barrel Input
Other I/O1 x Genlock (BNC)
1 x LANC (2.5 mm)
Card SlotNone
Wi-FiNone
Format Support
Video FormatHDMI (8/10-Bit 4:2:2)
DCI 4K: 60/59.94/50/30/29.97/25/24/23.98
UHD 4K: 60/59.94/50/30/29.97/25/24/23.98
DCI 2K: 240/200/120/100/60/59.94/50/30/29.97/25/24/23.98
1080p: 240/120/100/60/59.94/50/30/29.97/25/24/23.98
SDI (8/10-Bit 4:2:2)
DCI 4K: 60/59.94/50/30/29.97/25/24
UHD 4K: 60/59.94/50/30/29.97/25/24/23.98
DCI 2K: 240/200/120/100/60/59.94/50/30/29.97/25/23.98
1080p: 120/100/60/50/30/29.97/25/24/23.98
Gamma CurveARRI Log C, Canon Log, Canon Log 2, DCI-P3, DCI-P3+, FujiFilm F-Log, HDR-HLG, HDR-PQ, JVC J-Log, Panasonic V-Log, REDlogFilm, Sony S-Log 2, Sony S-Log 3
PC Resolutions1920 x 1080 at 60 Hz
Video Signal ConversionHDMI to SDI

SDI to HDMI
Recording
Pulldown Conversion2:2, 3:2
Camera TriggerSDI, HDMI
Pre-Roll Record4K: 2 Seconds
Full HD: 8 Seconds
Encoding Formats4096 x 2160
ProRes Raw
CinemaDNG
DNxHD
3840 x 2160
ProRes Raw
CinemaDNG
DNxHD
2048 x 1080
ProRes Raw
CinemaDNG
DNxHD
1920 x 1080
ProRes
DNxHD
Maximum Audio Tracks8
Recording Media1 x 2.5" SSD (SATA III)
Metadata Tagging10
Timecode SupportSMPTE 12M via BNC Input
Phantom Power+48 V
Power
DC Input Power6.2 to 16.8 VDC
Battery Type2 x L-Series
Power Consumption33 W (Maximum)
Mounting
Mounting2 x 1/4"-20 Female
Environmental
Operating Temperature104°F / 40°C
General
Material of ConstructionPolycarbonate
Dimensions (W x H x D)8.43 x 5 x 1.77" / 214 x 127 x 45 mm
Weight1.62 lb / 738 g
